Product Description

MPN: Shotgun Microphone

Sony ECM-G1 Wireless Compact Shotgun Microphone Specification

Microphone Specification

Basic Specs

• Model Name: Shotgun Microphone
• Dimension(Approx.): Diameter 20 mm x Length 176 mm (13/16 inches x 7 inches)
• Weight(Approx.): 102 g (3.6 oz)
• Operating Temperature: 0 ? to +60 ? (+32 °F to +140 °F)

Microphone

• Power Supply from Main Unit: External power supply 44 V to 52 V DC

• Current consumption: 4 mA or less
• Type: Electret condenser microphone
• Monaural / Stereo: Monaural

• Directivity: super cardioid

• Frequency response: 40 Hz to 40 000 Hz
• Front sensitivity: -31 dB (0 dB=1 V/Pa, 1 kHz)
• Signal-to-Noise ratio: 78 dB SPL or more (IEC 179 A-weighted, 1kHz, 1Pa)

• Intrinsic noise: 16 dB SPL or less (0 dB = 2×10^-5 Pa)

• Maximum input sound pressure level: 133 dB SPL

• Dynamic range: 117 dB SPL or more

• Microphone output: Yes (XLR 3-pin)

• Output impedance: 40 OHM

Supplied Accessories

• Name / Model (Count): Foam wind screen (1)

• Name / Model (Count): Fur wind screen (1)

• Name / Model (Count): Microphone holder (1)

• Name / Model (Count): Microphone spacer (molded type) (1)

• Name / Model (Count): Microphone spacer (sheet type) (1)

• Name / Model (Count): Microphone cable (1)

• Name / Model (Count): Storage case (1)

• Name / Model (Count): Stand adaptor (2)

MPN: Shotgun Microphone
